Heavy hammer crusher

  At present, the sand and gravel industry is in full swing, and investors in sand and gravel enterprises are increasingly diversifying their equipment. Many investors want to invest less and get quick results. In general, the sand industry equipment configuration of a broken jaw were selected, two stage crushing selection of back breaking or cone crusher, three stage crushing used sand making machine, large investment, high cost, not suitable for small and medium sized enterprises.

  The hammer crusher is the best equipment to solve the above problems. The following is our company heavy hammer broken product introduction：
  Special stone hammer crusher is my company for the gravel production equipment of medium and small investors and less investment and quick, the fusion of the traditional single stage hammer crusher and impact crusher characteristics, especially suitable for crushing medium hard limestone, the compressive strength is less than or equal to 200MPa, and the amount of calcium than stone 40%. Can realize one machine multi-purpose, can be used for a break, to achieve a molding, can also be used for two broken (two broken can choose the special counterattack crusher, get good particle shape), reduce the investment cost of 30~40%. At the same time, this model has the advantages of high output, low energy consumption and low cost.

  Both the shape and the structure of the heavy hammer crusher and the stone counter crusher are basically the same, and the difference is only in the form of the rotor. Hammer crusher rotor with the hammer, hammer can rotate around the axis, special stone crusher rotor with high chromium plate hammer, hammer crusher hammer weight, single rotor speed, reasonable hammer inertia, can be expected to have a large size, a small particle size of the crushing effect.
  Special gravity crusher for stone can be equipped with low voltage motor, high voltage motor and double motor.

Performance characteristics

1, a machine multi-purpose, can be used for a break, can also be used for two broken (eat back material), but also can be achieved once forming (single broken)
2, no grate design, high yield
3, a molding, simplify the process
4, reduce investment costs by 40%
5,low energy consumption design

General Technical Parameters:

Model	Feed Opening(mm)	Max Feed Size(mm)	Discharging Size(mm)	capacity(t/h)	Power(kw)
HC0808	800×750	780×610	≤500	50-80	75-90
HC1010	1000×1018	1040×800	≤650	120-150	90×2
HC1210	1200×1018	1250×800	≤750	150-200	110×2
HC1512	1500×1160	1210×900	≤800	250-400	160×2
HC1615	1675×1510	1480×1200	≤900	400-900	220×2
HC1820	1800×1964	2000×1200	≤1000	800-1500	6-800
HC2020	1920×2000	2010×1200	≤1100	1200-1600	6-800
HC2125	2100×2486	2600×1690	≤1200	2000-3000	6-1250
HC3032	3000×3220	3240×1840	≤1500	4000-6000	1250×2

technical parameter：

Model	Feed Opening(mm)	Max Feed Size(mm)	Discharging Size(mm)	capacity(t/h)	Power(kw)
ZPC1418	Φ1420*1750	≤700	≤150	250-400	320-400
ZPC1620	Φ1650*2000	≤900	≤200	500-800	630
ZPC1820	Φ1820*2000	≤1000	≤200	700-1000	800
ZPC2025	Φ2020*2550	≤1200	≤250	900-1400	900-1120
ZPC2328	Φ2300*2800	≤1200	≤300	1400-2000	1420-1800

Attachment: technical parameters for counterattack crusher used for back crushing, crushing and reshaping：

Model	Feed Opening(mm)	Max Feed Size(mm)	Discharging Size(mm)	capacity(t/h)	Power(kw)
FPC1418	Φ1420*1750	≤300	≤40	200-350	320-400
FPC1620	Φ1650*2000	≤300	≤60	400-600	560-630
FPC1820	Φ1820*2000	≤300	≤60	550-750	630-710
FPC2025	Φ2020*2550	≤400	≤80	700-1000	800-1000
FPC2328	Φ2300*2800	≤400	≤80	1260-1600	1260-1600

PZC hammer crusher equipment technical parameters: (PCZ heavy)

Model	Feed Opening(mm)	Max Feed Size(mm)	Discharging Size(mm)	capacity(t/h)	Power(kw)
PCZ1308	1310×790	850×800	≤600	100-160	132
PCZ1510	1500×900	1000×90	≤700	160-210	132×2
PCZ1512	1500×1160	1200×900	≤750	250-320	160×2
PCZ1615	1650×1452	1500×1200	≤1000	360-420	200×2
PCZ1620	1660×1900	2000×1200	≤1200	500-800	400×2
PCZ1820	1800×2000	2000×1200	≤1200	700-900	450×2

PCZ hammer crusher equipment technical parameters: (PCZ standard type)

Model	Feed Opening(mm)	Max Feed Size(mm)	Discharging Size(mm)	capacity(t/h)	Power(kw)
PC-0706	700×570	618×510	≤400	50-70	75
PC-0808	800×750	780×610	≤500	80-100	132
PC-0910	900×1000	1070×750	≤600	150-200	110×2
PC-1012	1000×1180	1255×810	≤650	250-300	132×2
PC-1213	1200×1280	1350×900	≤750	300-350	160×2
PC-1216	1200×1600	150×1000	≤850	400-450	160×2
PC-1220	1200×2000	2000×900	≤850	400-500	200×2

Note: The above technical parameters are for reference only. The latest data shall be subject to the formal quotation from our company. Please feel free to leave us a message for more details.
